Hdpe Pe Pipe Making Machine

China Comrise is a professional manufacture for advanced hdpe pe pipe making machine. With have 20 more years experience in the plastic extrusion machinery field and own R&D team, experienced international sales team, patient and on time service team, their product are well known by customers home and abroad.

Send Inquiry

Product Description

Comrise as suppiler of hdpe pe pipe making machine, who is designed for high-quality and efficient pipe production lines. hdpe pe pipe making machine is fully automated, equipped with advanced control systems and sensors to ensure consistent and high-quality production. The machine line can produce pipes with a wall thickness up to 3mm and a maximum speed of 15m/min.


Comrise machinery supply high output and high efficient hdpe pe pipe making machine with 5 five years warranty. Comrise adopt high efficient screw and barrel with spraying alloy treatment, which is durable, greatly extending service life. Also the hdpe pe pipe making machine mold with high quality material, spiral mold body design, and with reasonable internal flow channel design, which make the finished product smooth and beautiful.


The fancy hdpe pe pipe making machine manufactured by Comrise, products widely used  in various industries, including water supply and drainage, gas transportation, mining, agriculture, and telecommunications.


The weight per meter for HDPE hdpe pe ppr pipe extrusion machine line

HDPE water supply  pipe machine weight per meter table

OD
mm

SDR26

SDR21

SDR17

SDR13.6

SDR11



PressureMpa



0.6

0.8

1.0

1.25

1.6



Wall thickness

Weight
kg/m

Wall thickness

Weight
kg/m

Wall thickness

Weight
kg/m

Wall thickness

Weight
kg/m

Wall thickness

Weight
kg/m

φ20





1.2

0.068

1.5

0.084

1.8

0.099

2.3

0.123

φ25





1.4

0.100

1.8

0.126

2.2

0.151

2.3

0.157

φ32

1.2

0.111

1.5

0.138

1.9

0.172

2.4

0.214

3

0.262

φ40

1.4

0.163

1.9

0.218

2.3

0.262

2.9

0.324

3.7

0.405

φ50

1.8

0.262

2.3

0.331

2.9

0.412

3.7

0.517

4.6

0.630

φ63

2.2

0.403

3.0

0.543

3.7

0.662

4.7

0.826

5.8

1.001

φ75

2.6

0.558

3.5

0.755

4.5

0.957

5.6

1.172

6.8

1.299

φ90

3.2

0.838

4.3

1.111

5.4

1.378

6.7

1.683

8.2

2.023

φ110

4.2

1.340

5.3

1.574

6.6

2.058

8.1

2.489

10.0

3.016

φ125

4.8

1.740

6.0

2.153

7.4

2.625

9.2

3.213

11.4

3.906

φ140

5.4

2.192

6.7

2.694

8.3

3.297

10.3

4.029

12.7

4.876

φ160

6.2

2.876

7.7

3.537

9.5

4.312

11.8

5.274

14.6

6.402

φ180

6.9

3.602

8.6

4.446

10.7

5.453

13.3

6.687

16.4

8.098

φ200

7.7

4.466

9.6

5.513

11.9

6.751

14.7

8.216

18.2

9.979

φ225

8.7

5.644

10.8

6.977

13.4

8.651

16.6

10.433

20.5

12.643

φ250

9.6

6.960

11.9

8.545

14.8

10.498

18.4

12.852

22.7

15.561

φ280

10.7

8.690

13.4

10.774

16.6

13.187

20.6

16.116

25.4

19.503

φ315

12.1

11.054

15.0

13.572

18.7

16.711

23.2

20.417

28.6

24.703

φ355

13.6

14.003

16.9

17.233

21.1

21.248

26.1

25.889

32.2

31.348

φ400

15.3

17.751

19.1

21.941

23.7

26.897

29.4

32.860

36.3

39.817

φ450

17.2

22.451

21.5

27.834

26.7

34.086

33.1

41.618

40.9

50.463

φ500

19.1

27.702

23.9

34.317

29.7

42.126

36.8

51.408

45.4

62.245

φ560

21.4

34.761

26.7

42.944

33.2

52.747

41.2

64.464

50.8

78.013

φ630

24.1

44.039

30.0

54.286

37.4

66.842

46.3

81.506

57.2

98.818

φ710

27.2

56.012

33.9

69.124

42.1

84.803

52.2

103.557

64.5

125.741

φ800

30.6

71.005

38.1

87.547

47.4

107.587

58.8

121.441

72.6

159.466


PE water supply pipe standard-(GB/T 13663-2000)

This standard specifies the product specifications, technical requirements, test methods, inspection rules, marking, packaging, transportation, Storage. This standard also specifies basic performance requirements for raw materials, including a classification system.


This standard applies to water supply pipes made of PE63, PE 80 and PE 100 materials. The nominal pressure of the pipe is 0.32MPa~1.6MPa, and the nominal outer diameter is 16 mm~1000 mm.


The pipes specified in this standard are suitable for general-purpose pressure water transmission at temperatures not exceeding 40C, as well as for the transportation of drinking water.


Why is HDPE used for hdpe pe ppr pipe ?

High-density polyethylene (HDPE) pipes are effective for the large scale transfer of liquids given that they can withstand high amounts of pressure and are unaffected by rust due to their thermoplastic quality. Unlike traditional metal pipe fittings, HDPE pipes do not rust, corrode or rot.


Product application scenarios



Hot Tags: Hdpe Pe Pipe Making Machine, China, Manufacturer, Supplier, Factory, Customized, Cheap, Quality
