PE Pipe Production Line for Irrigation
If you are in search of an efficient and reliable irrigation solution, look no further than the professional supplier comrise PE Pipe Production Line for Irrigation. With the latest technology and quality materials, comrise production line is designed to meet all your irrigation needs.
Send Inquiry
Product Description
One of the outstanding features of comrise machinery pe pipe production line for irrigation is its user-friendly interface. The machine comes with an intuitive control panel that is easy to navigate, even for those new to the industry. This feature makes the pe pipe production line for irrigation more accessible, and our customers can start producing pipes and tubes without the need for extensive training.
Comrise discount PE pipe production line for irrigation is made up of high-quality components that are built to last. It provides a cost-effective solution for your irrigation requirements. The PE pipe production line for irrigation operates with ease, manufacturing pipes with diameters ranging from 16mm to 1200mm. Each pipe produced is of superior quality and strength, with a long-lasting life span that guarantees the best return on your investment.
China pe pipe production line for irrigation is designed to withstand harsh weather conditions and constant usage, PE pipes are manufactured from top-grade materials that are environmentally friendly. The pipes are also UV-resistant, making them ideal for outdoor use, ensuring they retain their structural integrity and high-performance as irrigational systems.
GET A QUOTATION NOW
The weight per meter for HDPE hdpe pe ppr pipe extrusion machine line
|
HDPE water supply pipe machine weight per meter table |
||||||||||
|
OD |
SDR26 |
SDR21 |
SDR17 |
SDR13.6 |
SDR11 |
|||||
|
|
PressureMpa |
|||||||||
|
|
0.6 |
0.8 |
1.0 |
1.25 |
1.6 |
|||||
|
|
Wall thickness |
Weight |
Wall thickness |
Weight |
Wall thickness |
Weight |
Wall thickness |
Weight |
Wall thickness |
Weight |
|
φ20 |
|
|
1.2 |
0.068 |
1.5 |
0.084 |
1.8 |
0.099 |
2.3 |
0.123 |
|
φ25 |
|
|
1.4 |
0.100 |
1.8 |
0.126 |
2.2 |
0.151 |
2.3 |
0.157 |
|
φ32 |
1.2 |
0.111 |
1.5 |
0.138 |
1.9 |
0.172 |
2.4 |
0.214 |
3 |
0.262 |
|
φ40 |
1.4 |
0.163 |
1.9 |
0.218 |
2.3 |
0.262 |
2.9 |
0.324 |
3.7 |
0.405 |
|
φ50 |
1.8 |
0.262 |
2.3 |
0.331 |
2.9 |
0.412 |
3.7 |
0.517 |
4.6 |
0.630 |
|
φ63 |
2.2 |
0.403 |
3.0 |
0.543 |
3.7 |
0.662 |
4.7 |
0.826 |
5.8 |
1.001 |
|
φ75 |
2.6 |
0.558 |
3.5 |
0.755 |
4.5 |
0.957 |
5.6 |
1.172 |
6.8 |
1.299 |
|
φ90 |
3.2 |
0.838 |
4.3 |
1.111 |
5.4 |
1.378 |
6.7 |
1.683 |
8.2 |
2.023 |
|
φ110 |
4.2 |
1.340 |
5.3 |
1.574 |
6.6 |
2.058 |
8.1 |
2.489 |
10.0 |
3.016 |
|
φ125 |
4.8 |
1.740 |
6.0 |
2.153 |
7.4 |
2.625 |
9.2 |
3.213 |
11.4 |
3.906 |
|
φ140 |
5.4 |
2.192 |
6.7 |
2.694 |
8.3 |
3.297 |
10.3 |
4.029 |
12.7 |
4.876 |
|
φ160 |
6.2 |
2.876 |
7.7 |
3.537 |
9.5 |
4.312 |
11.8 |
5.274 |
14.6 |
6.402 |
|
φ180 |
6.9 |
3.602 |
8.6 |
4.446 |
10.7 |
5.453 |
13.3 |
6.687 |
16.4 |
8.098 |
|
φ200 |
7.7 |
4.466 |
9.6 |
5.513 |
11.9 |
6.751 |
14.7 |
8.216 |
18.2 |
9.979 |
|
φ225 |
8.7 |
5.644 |
10.8 |
6.977 |
13.4 |
8.651 |
16.6 |
10.433 |
20.5 |
12.643 |
|
φ250 |
9.6 |
6.960 |
11.9 |
8.545 |
14.8 |
10.498 |
18.4 |
12.852 |
22.7 |
15.561 |
|
φ280 |
10.7 |
8.690 |
13.4 |
10.774 |
16.6 |
13.187 |
20.6 |
16.116 |
25.4 |
19.503 |
|
φ315 |
12.1 |
11.054 |
15.0 |
13.572 |
18.7 |
16.711 |
23.2 |
20.417 |
28.6 |
24.703 |
|
φ355 |
13.6 |
14.003 |
16.9 |
17.233 |
21.1 |
21.248 |
26.1 |
25.889 |
32.2 |
31.348 |
|
φ400 |
15.3 |
17.751 |
19.1 |
21.941 |
23.7 |
26.897 |
29.4 |
32.860 |
36.3 |
39.817 |
|
φ450 |
17.2 |
22.451 |
21.5 |
27.834 |
26.7 |
34.086 |
33.1 |
41.618 |
40.9 |
50.463 |
|
φ500 |
19.1 |
27.702 |
23.9 |
34.317 |
29.7 |
42.126 |
36.8 |
51.408 |
45.4 |
62.245 |
|
φ560 |
21.4 |
34.761 |
26.7 |
42.944 |
33.2 |
52.747 |
41.2 |
64.464 |
50.8 |
78.013 |
|
φ630 |
24.1 |
44.039 |
30.0 |
54.286 |
37.4 |
66.842 |
46.3 |
81.506 |
57.2 |
98.818 |
|
φ710 |
27.2 |
56.012 |
33.9 |
69.124 |
42.1 |
84.803 |
52.2 |
103.557 |
64.5 |
125.741 |
|
φ800 |
30.6 |
71.005 |
38.1 |
87.547 |
47.4 |
107.587 |
58.8 |
121.441 |
72.6 |
159.466 |
PE water supply pipe standard-(GB/T 13663-2000)
This standard specifies the product specifications, technical requirements, test methods, inspection rules, marking, packaging, transportation, Storage. This standard also specifies basic performance requirements for raw materials, including a classification system.
This standard applies to water supply pipes made of PE63, PE 80 and PE 100 materials. The nominal pressure of the pipe is 0.32MPa~1.6MPa, and the nominal outer diameter is 16 mm~1000 mm.
The pipes specified in this standard are suitable for general-purpose pressure water transmission at temperatures not exceeding 40C, as well as for the transportation of drinking water.
Why is HDPE used for hdpe pe ppr pipe ?
High-density polyethylene (HDPE) pipes are effective for the large scale transfer of liquids given that they can withstand high amounts of pressure and are unaffected by rust due to their thermoplastic quality. Unlike traditional metal pipe fittings, HDPE pipes do not rust, corrode or rot.
Product application scenarios
GET A QUOTATION NOW
